Typical Process for Ferrite Magnetic Products
Manufacturing Flow Chart
Start
Raw material
Pre-calcination
Pre-calcination
Crushing Milling
Pressing
Sintering
Grinding Cleaning
Packing
…………
Ball milling machine:1.5T /28sets
Ball milling machine:4T /6sets
Dry pressing machines:63T /10sets, 125T/8sets
Wet pressing machines:150T /92sets, 230-250T/12 sets
Auto electric kilns 45m: 6sets+ natural gas kilns: 2sets
Auto grinding production lines: 31sets
5 sets Sodick WEDM- LS Machines
Sodick EDM Equipment
Injection molding machine
Horizontal injection molding machine: 35 sets (tonnage 100-250T)
立式注塑机Vertical injection molding machines: 24 sets
Quality Testing Center
Contourgraph
CMM
Projector
Bosch Robograph RE
Magnetic energy testing instrument
Multi pole waveform tester
Magnetic flux tester
High-low temp. test chamber
